Seawall Repair With Chemical Grouts

You can repair a seawall or bulkhead with Prime Resins chemical grouts: fill voids, stabilize loose soil and seal leaks at a fraction of the cost of wall replacement.

A property owner is plagued by a failing seawall. Soil washes away with every wave or tidal cycle through gaps in or under the wall. Maybe the wall joints are failing. Perhaps the footer no longer meets a solid foundation.

The symptoms are clear

The ground is caving in behind the wall. Voids are visible. Sinkholes are forming. Nearby walkway, sidewalk, patio or pool deck slabs have settled, resulting in trip and fall hazards. Unseen consequences can include compromised foundations of adjacent structures.

close up diagram of water penetrating through cracks in a concrete seawall

Cracks or failing joints in a seawall can cause erosion behind the wall, compromising the integrity of the structure

These symptoms are caused by erosion of the ground behind the wall. Typically, this is caused by leaks in the wall, improper drainage of land-side runoff, or ground behind the wall that was not sufficiently compacted during construction. The latter can happen when the original contractor worries about putting too much force against the wall and consequently doesn’t tamp the earth hard enough. Over time that ground will settle or will get saturated and mushy. Either will result in voids and erosion, undermining the integrity and effectiveness of the wall.

Seawall Repair Options

You could fill voids with dirt and aggregate or a cementitious fill. But this won’t remove the reason there is erosion or settlement in the first place.

You could replace some or all of the wall. That is a major construction project that is highly disruptive to the property owner and possibly to the environment. An environmentally sensitive area could mean an extensive (and expensive) permitting process, delaying remedy by weeks or months. Depending on the location, you could be looking at needing to use a barge or crane to do the construction.

There are absolutely times when replacement is the best or only option. That is often not the case though.

What if?

What if you could:

  • seal the failing joints in a wall
  • stabilize loose, saturated soil
  • fill voids behind the wall without adding huge weight to a weak substrate
  • create a watertight barrier behind and under a wall, all without excavation?

And what if you could do all of that with material so eco-friendly that it is certified for contact with drinking water?

Yes, you can

You can do all those things with polyurethane injection resins from Prime Resins. For 35 years, our products have been used to stabilize soil, seal leaks, and repair concrete—including more than 200 seawalls and bulkheads.

Illustration of seawall repair with Prime Flex 920 from Prime Resins

One example

Imagine coming home from vacation to find your back yard disappearing into a sinkhole beside the bulkhead. That’s what happened to one homeowner on Lake Harris in Lake City, Florida. The bulkhead is only 15 feet from the foundation, so she had visions of her very expensive home falling into the lake. Steps were taken to address several issues. The large voids were filled and the failing wall joints were sealed using Prime Flex 920. The product is a hydrophobic polyurethane resin that is certified to comply with NSF/ANSI Standard 61 for contact with potable water.

The homeowner was thrilled with the results, which will last decades. Her short-term options would have saved her money upfront, but the long-term cost of seawall failure or foundation damage to her home would have been 400% to 500% higher than what she spent on permeation grouting with Prime Flex 920.

Here are your options

Prime Flex 910 Hydrophobic single-component polyurethane resin with a very low viscosity that reacts with moisture when injected into soil forming a rock hard, water-tight mass. Used to stabilize loose soil or sand, stop underground water flows and seal leaking seawalls.
Prime Flex 920 Independently tested and certified as compliant with NSF/ANSI Standard 61.5 for contact with potable water. Hydrophobic, super low viscosity polyurethane that reacts with water and expands to form a closed cell, watertight, rigid foam. Used for filling voids and for permeation grouting of loose soils to consolidate soil particles and stop erosion.
Prime Flex 985 LX20 For filling large voids and voids under load-bearing concrete structures. Versatile, two-component, low exotherm polyurethane foam used to fill voids, stabilize soil and underseal concrete slabs. Very low viscosity allows for moderate permeation. Independently tested and certified as compliant with NSF/ANSI Standard 61.5 for contact with potable water.
Prime Flex 900 XLV Used with oakum for sealing large joints or defects in concrete seawalls. Hydrophilic resin that reacts with water, so excellent bond with concrete for sealing cracks and failed seawall joints. Independently tested and certified as compliant with NSF/ANSI Standard 61.5 for contact with potable water.
AR 800 Multi-component acrylate resin system that forms an elastomeric gel when cured. Recommended for permeation grouting in extremely fine, “sugar” sand. Adjustable set time gives flexibility and allows for thorough permeation. Independently tested and certified as compliant with NSF/ANSI Standard 61.5 for contact with potable water.

Perfect partner

If you do need to replace some or all of the wall, or if you are installing tiebacks, helicals or some other shoring method, Prime Flex products are the perfect complement to these solutions. You have repaired the wall, but voids remain behind it. Prime Flex 910, 920 or 985 LX20 are options for filling those voids.

New to chemical grouting?

  • No specialty equipment required. Injecting polyurethane resins requires only a simple lightweight electric pump such as a Titan 540 or 640 and probes to deliver the material into the void. (The AR 800 acrylate does require equipment with all stainless steel wetted parts.)
  • Training is available. We provide on-site technical service or training on a fee-for-service basis. Twice a year we offer the Prime Resins Chemical Grouting Institute at our Atlanta-area headquarters.

Save your client’s seawall. Rescue their property from the sea or lake. You can be the hero who offers them a permanent solution to their erosion problem at a fraction of the cost and disruption of replacement.

Call one of our technical consultants today at 800-321-7212 for more information on seawall repair or fill out the form below.
